BOSCH, Readers and Accessories
ARD-AYBS6260 Card reader, MIFAREclassic
- Two interfaces – RS485 and Wiegand
- For use with MIFARE classic cards and key-fobs
- IP65 rated for indoor and outdoor use
- Wall or mullion mount
- Tamper switch
129.60 € excl. VAT
Key Specifications
| Input voltage | 8.5 V to 16 Vdc – max. 18 Vdc |
| Current draw | 65 mA @ 12 VdcMax.: 130 mA @ 12 Vdc |
| Tamper output | Open collector, active low, 32 mA max sink current. Optical Technology |
| Wiegand D0 output | 5 V (TTL) |
| Wiegand D1 output | 5 V (TTL) |
| Green LED control input | Active low |
| Red LED control input | Active low |
| Buzzer control input | Active low |
| RS485 | OSDP protocol |
| Wiegand IF | D0/D1 Wiegand protocol |
| Keypad | none |
| Operating environment | Indoor and outdoor use – all weather. |
| Operating temperature | -25 °C to 65 °C (-13 °F to 150 °F) |
| Operating humidity | 0 to 95% (Non-condensing) |
| IP rating | IP65 |
| UV-light resistant | Yes |
| Vandal resistance | IK08 |
| Read range – ISO cards | > 6 cm (2.36 in.) |
| Key fob | > 2 cm (0.78 in.) |
| Supported cards | MIFARE 13.56 MHzISO 14443 Type A |
Parts included with this product
| Quantity | Component |
|---|---|
| 1 | Reader |
| 1 | Back plate |
| 1 | Mounting frame |
| 2 | Screw anchors |
| 2 | Small screws (silver) |
| 2 | Small screws (black) |
| 2 | Long screws |
| 1 | Screw wrench |
| 1 | Mounting template |
| 1 | Installation manual |
