KNX-BIN24 Universal Binary Input Module

Features:

• Number of inputs (zones)
  8
• Enclosure dimensions
  70 x 92 x 60 mm
• Operating temperature range
  0°C…+45°C
• Weight
  144 g
• IP code
  IP20
• Maximum tightening torque
  0,5 N·m
• Temperature range for storage / transport
  -25°C…+70°C
• Number of units on DIN rail
  4
• Certificate of conformity
  nr 324/13957//17
• Maximum cross-section of wire
  2.5 mm²
• Current draw from KNX bus
  < 15 mA
• Maximum time of response to telegram
  < 20 ms
• Maximum number of communication objects
  108
• Maximum number of group addresses
  256
• Maximum number of associations
  256
• Supply voltage (KNX bus)
  20…30 V DC
• Input current Iₙ
  1,5 mA
• Acceptable voltage range Uₙ
  0…30 V AC/DC
• Voltage range for Uₙ₀ signal
  0…4 V AC/DC
• Voltage range for Uₙ₁ signal
  9…30 V AC/DC
