SATEL OPAL Outdoor PIR + MW Motion Detector
, ,

OPAL Outdoor PIR + MW Dual Technology Motion Detector


  • Dual technology motion detector for outdoor/indoor installation
  • Passive infrared sensor
  • Microwave sensor
  • Antimasking
  • 15m range
  • Animal immunity up to 20kg
  • Temperature compensation
  • Sensitivity adjustment
  • Working temperature from -40°C up to +55°C
  • IP54
  • 12VDC/20mA
  • GRADE 2

48.28  excl. VAT

SATEL OPAL Outdoor PIR + MW Dual Technology Motion Detector

The OPAL is an outdoor dual technology motion detector, which is perfectly suited for application both on the outside of the protected building as well as indoors, where difficult or specific environmental conditions prevail (in halls, under umbrella roofs, etc.). The OPAL detector incorporates PIR and MW technologies, as well as antimasking function based on the microwave technology. The dual technology combined with the algorithm of detector auto-tuning to the environmental conditions ensures high immunity to false alarms and, consequently, stable operation in harsh weather conditions, such as rain, snow, sunshine and strong gusts of air. The device offers correct operation in a wide temperature range from -40°C to +55°C, the ambient temperature changes being automatically compensated.

The OPAL detector has a detection angle as wide as 100 degrees and a reach of more than 15 meters. Also, as the look down zone is protected, any intruder’s attempt to approach the device to damage it or pull it off will be detected. In addition, the detector software has been designed so as to avoid false alarms caused by the movement of small pets.

PIR PIR
Sensitivity Yes
Range 15м
Temperature compensation Yes
Working temperature от -40°C до +55°C
Anti-masking Yes
Pet immunity Up to 20 kg
Outdoor installation IP IP54
Wired / Wireless Wired
Maximum current consumption 12VDC, 20mA
EN-50131 GRADE GRADE 2
