SATEL NAVY Dual Technology PIR And Glass-Break Detector
, ,

NAVY Dual Technology PIR And Glass-Break Detector


  • Digital combined acoustic and passive infrared detector
  • Detection of break of tempered and laminated glass
  • Range of acoustic detection – 6 m
  • Dual element PIR
  • Digital detection algorithm of new generation
  • Digital temperature compensation
  • Precision Fresnel lens
  • Alarm memory
  • Immunity to animals up to 15kg.
  • Independent smooth adjustment of sensitivity
  • 90°, 12x13m
  • Two independent relay outputs
  • 12VDC/10mA

23.31  excl. VAT

SATEL NAVY Dual Technology PIR And Glass-Break Detector

NAVY dual technology detector combines the motion detection using PIR technology with acoustic glass-break detector. This combination is an ideal solution for complex protection of rooms with large windows. Independent alarm outputs for both motion and glass-break detection allows the control panel to precisely identify the source of alarm.

PIR Dual PIR element
Sensitivity Yes
PIR range 90°, 12х13м
Acoustic detector range
Temperature compensation Yes
Working temperature
Pet immunity Up to 15 kg
Wired / Wireless Wired
Maximum current consumption 12VDC, 10mA
EN-50131 GRADE
