NAVY Dual Technology PIR And Glass-Break Detector

Features:

• Supply voltage
  12 V DC
• Detected target velocity
  0,3…3 m/s
• Operating temperature range
  -10…+55 °C
• Recommended mounting height
  2,4 m
• Standby mode current consumption
  7,5 mA
• Max. current consumption
  10 mA
• Weight
  100 g
• Relay contacts rated load (resistive)
  40 mA / 16 V DC
• Maximum humidity
  93±3%
• Dimensions
  63 x 96 x 49 mm
• Environmental class according to EN50130-5
  II
• Alarm signaling time
  2 s
• Warm-up period
  30 s
• Glassbreak detection range
  up to 6 m
