Accessories, PARADOX
PRT3 Integration Module
- In-field firmware upgradeable via a CONV4USB and WinLoad
- Supports ASCII / C-BUS protocols
- 16 virtual inputs to trigger an action in the EVO control panel based on an event received from the peripheral system using ASCII or C-BUS protocol
- 30 virtual PGMs to trigger an action in the peripheral system using ASCII or CBUS protocol based on an event received from the EVO control panel
- USB port for PC connections
- Provides an interface between an EVO control panel and a third party peripheral system
- Automatically/manually print reports of zones/systems event via printer and/or PC
- Parallel and serial port for printer connections
- Assign to one or more partitions
- 2048 event buffer
- Available in English
84.50 € excl. VAT
PRT3 Integration Module
Based on 0 reviews
Be the first to review “PRT3 Integration Module”
Related products
-
PARADOX, Keypads
K10H 10-Zone Hardwired LED Keypad Module (Horizontal)
- Supports StayD Mode
- 10-zone LED display
- Separate Arm, Sleep, Stay and Off LEDs per partition
- Patented Key Light display (button lights up to indicate an open zone)
- 1 keypad zone input
- Independently set chime zones
- 7 one-touch action buttons
- 3 keypad-activated panic alarms
- Adjustable backlight
- Connects to 4-wire communication bus
- Compatible with MG5000, MG5050, MG5075, and Spectra SP series
SKU: K10H -
-
PARADOX, Keypads
K32LCD+ 32-Character Hardwired LCD Keypad Module
- Beautiful new design
- 32-character blue LCD with programmable labels
- Real-time zone alarm display (until disarmed)
- In-field firmware upgrade via 307USB
- StayD status LED
- Menu-driven programming for easy system setup (installer and end user)
- 1 keypad zone input
- Independently set chime zones
- 8 one-touch action buttons
- 3 keypad-activated panic alarms
- Adjustable backlight, contrast and scroll speed
- Connects to 4-wire expansion bus
- Compatible with MG5000, MG5050, MG5075, and Spectra SP series V2.31 and up
- Compatible with SP4000, SP65 V4.90 and up
SKU: K32LCD+ -
PARADOX, Door Contacts
DCT6 Wireless Door Contact
- Selectable 433 Mhz
- Durable long life cost effective alkaline battery
- Indoor range of 40 to 70 m (130 to 230 ft)
- Anti-Tamper switch (Cover opening)
- Powerful magnet guaranteed to operate at 10 mm (0.4 in.)
- Supervised and battery level monitored
SKU: DCT6
