Cameras, DAHUA Systems, IP Video Surveillance
IPC-HDW3649H-AS-PV-PRO-0280B 6MP WizColor TiOC PRO Eyeball Camera
MPN: IPC-HDW3649H-AS-PV-PRO-0280B
If in stock, ship in 1-2 days
179.06 € excl. VAT
Dahua IPC-HDW3649H-AS-PV-PRO-0280B 6MP WizColor TiOC PRO Smart Dual Light Eyeball IP Camera
Features:
| Brand | Dahua |
| Model | IPC-HDW3649H-AS-PV-PRO-0280B |
| Camera Type | Eyeball IP Network Camera |
| Product Series | WizSense / TiOC PRO / WizColor |
| Resolution | 6MP |
| Image Sensor | 1/1.8″ CMOS |
| Maximum Resolution | 3288 × 1850 |
| Scanning System | Progressive Scan |
| Electronic Shutter | 1/3s – 1/100,000s |
| Minimum Illumination | 0.0002 lux (Color, F1.0, 30 IRE) |
| Minimum B/W Illumination | 0.0001 lux (F1.0, 30 IRE) |
| Lens Type | Fixed-focal |
| Focal Length | 2.8mm |
| Maximum Aperture | F1.0 |
| Horizontal Viewing Angle | 109° |
| Vertical Viewing Angle | 59° |
| Diagonal Viewing Angle | 131° |
| Close Focus Distance | 3.2m |
| Night Vision Technology | WizColor / Smart Dual Light |
| IR Illumination Distance | Up to 30m |
| Warm-Light Distance | Up to 30m |
| Day/Night Mode | Auto (ICR) / Color / B&W |
| Wide Dynamic Range | 130dB WDR |
| Backlight Compensation | BLC / HLC |
| Noise Reduction | 3D NR |
| AI Image Processing | AI SSA |
| Video Compression | H.265 / H.264 / MJPEG |
| Smart Compression | Smart H.265+ / Smart H.264+ |
| AI Coding | Super AI Coding H.265 / H.264 |
| Maximum Frame Rate | 25/30 fps at 6MP |
| Video Streams | 3 |
| Bit Rate Control | CBR / VBR / ABR |
| Intelligent Motion Detection | SMD 4.0 |
| Human Detection | Yes |
| Vehicle Detection | Yes |
| Perimeter Protection | Yes |
| Intrusion Detection | Yes |
| Tripwire Detection | Yes |
| Stay / Loitering Detection | Yes |
| Face Detection | Yes |
| AcuPick | Yes, with compatible back-end devices |
| Active Deterrence | TiOC PRO |
| Warning Lights | Red and blue |
| Audible Alarm | Built-in siren / speaker |
| Built-in Microphones | 2 |
| Built-in Speaker | Yes |
| Two-Way Audio | Yes |
| Audio Input / Output | 1 / 1 |
| Alarm Input / Output | 1 / 1 |
| Memory Card Support | MicroSD up to 512GB |
| Network Interface | RJ-45, 10/100 Mbps |
| Network Protocols | IPv4, IPv6, HTTP, HTTPS, TCP, UDP, RTSP, RTP, DHCP, DNS, NTP and others |
| ONVIF Compatibility | Profiles S, G and T |
| Remote Management | DMSS, DSS, Smart PSS Lite |
| Power Supply | 12V DC ±30% / PoE (802.3af) |
| Maximum Power Consumption | 8.2W (12V DC) / 10W (PoE) |
| Protection Rating | IP67 |
| Housing Material | Metal |
| Operating Temperature | −40°C to +60°C |
| Operating Humidity | Up to 95% RH, non-condensing |
| Dimensions | Ø122 × 116.1mm |
| Net Weight | 0.8kg |
| Installation | Indoor / Outdoor |
| Focal Lenght | 2.8mm |
|---|---|
| Color Imaging | WizColor |
| Intelligent Functions | WizSense |
| Max Resolution | 6MP |
| Type | Eyeball |
