ABAX, SATEL Security Solutions, Wireless Systems
ACX-210 Miniature Wireless Expander
MPN: ACX-210
If in stock, ship in 1-2 days
30.40 € excl. VAT
ACX-210 Miniature Wireless Expander Of Wired Zones/Outputs
Features:
| Operating temperature range | -10°C…+55°C |
| Supply voltage | 4…24 V DC |
| Standby mode current consumption | 30 mA |
| Max. current consumption | 35 mA |
| Weight | 10 g |
| Maximum humidity | 93±3% |
| Operating frequency band | 868,0 ÷ 868,6 MHz |
| Dimensions | 21 x 41 x 13 mm |
| Environmental class according to EN50130-5 | II |
| Complied with standards | EN 50130-4, EN 50130-5 |
| Radio communication range (in open area) for ACU-120 | up to 500 m |
| Radio communication range (in open area) for ACU-270 | up to 500 m |
| Radio communication range (in open area) for ACU-220 | up to 2000 m |
| Radio communication range (in open area) for ACU-280 | up to 1400 m |
| Low-current outputs, OC type | 50 mA / 12 V DC |
For more information: ACX-210
