Access Controllers, BOSCH
APS-PSU-60 Power supply unit
- Supports 12 V/7 Ah, 12 V/14 Ah and 24 V/7 Ah batteries
- Selectable 12 VDC or 24 VDC voltage output
- Selectable 5 A @ 12 VDC or 2.5 A @ 24 VDC current output
- Overvoltage protection
- Regulates battery charging voltage
249.30 € excl. VAT
Key Specifications
| Output voltage: | 12V mode 24V mode, 10-15V 20-30V |
| Output current: | 12V mode 24V mode, max 5A max. 2.5A |
| Output power: | 60 W (constant) |
| Over voltage protection at: | 12V mode 24V mode, 16.5V 33V |
| Input voltage: | AC 100-240V~, 50-60Hz |
| Input current (AC): | Max. 2A, to the specified max. load at 85 VAC |
| Inrush current for 1ms: | AC 100-240V 30A |
| Output voltage: | 12V mode 24V mode, 10-15V 20-30V |
| Output current for charging the battery: | 12V mode 24V mode, 700mA * 350mA † |
| Protection from total battery discharge: | 12V mode 24V mode, 9.5V 19V |
| Working temperature: | -20°C to 60°C (-4°F to 140°F) |
| Working temperature (UL installations only): | 0°C to 49°C (32°F to 120°F) |
| Storage temperature: | -40°C to 85°C (-40°F to 185°F) |
| Relative humidity: | 5% to 95% |
Parts included with this product
| Quantity | Component |
|---|---|
| 1 | Power supply |
| 1 | Plug 1 x 2-pin for mains (primary AC) connection 3 x 2-pin 1 x 4-pin |
| 1 | NTC resistor |
| 1 | Accompanying documentation (installation manual) |
